Desired flexibility.
|
Type |
Deformed reinforcing steel bar |
|
Standard |
a. GB1499.2-2007, HRB335, HRB400, HRB400E, HRB500, HRB500E, etc. |
|
b. ASTM A615 Gr.40, Gr.60, etc. |
|
|
c. BS4449/1997, etc. |
|
|
Diameter |
6mm~ 32mm etc. |
|
Length |
6m,12m as standard |
|
Surface finished |
Screw-thread black |
|
Epoxy coating |
|
|
Galvanized coating |
|
|
Application |
construction industry with all types of reinforced concrete structures and so on. |
|
Package |
in Bundle with steel strips |
|
Packing |
standard export packing, or as per customers' requirement |
|
Shipment |
By bulk vessel or container |
|
Quality |
First quality |
|
Payment term |
30% T/T in advance, 70% balance before loading. |
|
Delivery time |
within 7~10 days after receiving the deposit. |
|
Others |
1. all the production process are made under the ISO 9001:2001 strictly |
|
2. our products conform to all the standards |
|
|
3. we can offer special specification products as per our customers |
|
Diameter |
Inner diameter |
Out diameter |
Theoretical weight |
|
(mm) |
(mm) |
(mm) |
(kg/m) |
|
6 |
5.75 |
6.75 |
0.222 |
|
8 |
7.5 |
9 |
0.395 |
|
10 |
9.3 |
11.3 |
0.617 |
|
12 |
11 |
13 |
0.888 |
|
14 |
13 |
15.5 |
1.209 |
|
16 |
15 |
17.5 |
1.579 |
|
18 |
17 |
20 |
2 |
|
20 |
19 |
22 |
2.468 |
|
22 |
21 |
24 |
2.986 |
|
25 |
24 |
27 |
3.856 |
|
28 |
26.5 |
30.5 |
4.837 |
|
32 |
30.5 |
34.5 |
6.318 |
6mm, 8mm, 10mm will be coil, more than 10mm will be straight steel bar.
If you need 6mm, 8mm, 10mm make it 6m or 12m, we can make it straight.
For the sizes more than 10mm, normal it will be 12m, if you need 6m, we can cut it to 6m.
