321 Stainless Steel Plate Sheet

Direct supply from the manufacturer: Order phone：+86-13526000457; E-mail：alice@liansen.vip

Detail

321 Stainless Steel Plate Sheet Description:

321 Stainless Steel Sheet is a titanium stabilized austenitic chromium-nickel stainless steel which was developed to provide an 18-8 type alloy with improved intergranular-corrosion resistance. This material is stabilized against chromium carbide formation by the addition of titanium. Since titanium has a stronger affinity for carbon than chromium, titanium carbide precipitates within the grains instead of forming at the grain boundaries. AISI 321 Stainless Steel Sheet should be considered for applications requiring intermittent heating between 800ºF (427ºC) and 1650ºF (899ºC), or for welding under conditions which prevent a post-weld anneal. 321 stainless steel is non-magnetic. We supply 321 stainless steel sheet in a variety of lengths and widths and can custom cut to your exact specifications.
Fast, Accurate precision profile cutting of simple or complex components can be offered to customers to have your job custom cut.

321 Stainless Steel sheet Processing:

321 Stainless Steel sheet Testing

321 Stainless Steel sheet Cutting

321 Stainless Steel sheet Grinding

321 Stainless Steel sheet Forming Drilling/ Machining

Stainless Steel 321 Grade Specification Comparison:

Grade	UNS No	Old British		Euro-norm		Swedish SS	Japanese JIS
		BS	En	No	Name
321	S32100	321S31	58B, 58C	1.4541	X6CrNiTi18-10	2337	SUS 321

Chemical Properties Of 321 Stainless Steel sheet:

Grade	C	Mn	Si	P	S	Cr	Mo	Ni	N	Other
321 min 321 max	- 0.08	- 2.0	- 0.75	0 0.045	- 0.03	17.00 19.00	2.00 3.00	9.00 12.0	- 0.10	Ti=5(C+N) 0.70

Mechanical Properties Of 321 Stainless Steel sheet:

Grade	Tensile Strength (MPa) min	Yield Strength 0.2% Proof (MPa) min	Elongation (% in 50mm) min	Hardness
				Rockwell B (HR B) max	Brinell (HB)max
321	515	205	40	95	217

Stainless Steel 321 sheet Physical Properties:

Grade	Density (kg/m3)	Elastic Modulus (GPa)	Mean Coefficient of Thermal Expansion(μm/m/°C)			Thermal Conductivity(W/m.K)		Specific Heat 0-100°C (J/kg.K)	Electrical Resistivity (nΩ.m)
			0-100°C	0-315°C	0-538°C	at 100°C	at 500°C
321	8027	193	16.6	17.2	18.6	16.1	22.2	500	720

321 Stainless Steel sheet Application:

321 Stainless Steel sheet Used in Tractor
321 Stainless Steel sheet Used in Automotive Trim
321 Stainless Steel sheet Used in Stamped Machined Products
321 Stainless Steel sheet Used in Cookware
321 Stainless Steel sheet Used in Appliances
321 Stainless Steel sheet Used in Kitchen
321 Stainless Steel sheet Used in Food-service Equipment
321 Stainless Steel sheet Used in Sinks
321 Stainless Steel sheet Used in Railway Cars
321 Stainless Steel sheet Used in Trailers
