Grade 316 Stainless Steel is the standard "18/8" stainless; it is the most versatile and most widely used stainless steel, available in a wider range of products, forms and finishes than any other. It has excellent forming and welding characteristics. The balanced Austenite structure of Grade 316 enables it to be severely deep drawn without intermediate annealing, which has made this grade dominant in the manufacture of drawn stainless parts such as sinks, hollow-ware and saucepans. For these applications it is common to use special "316DDQ" (Deep Drawing Quality) variants.
316 Stainless Steel Round Bar can be categorically said that steel bars are one of the core components of any manufacturing industry or for that matter any industry that relies on machine. versatile applications in automotive, textile, fabrication, construction, cement, ship building, paper and pulp, defence, heavy earth moving equipment or aerospace.
Our offered 316 Stainless Steel Round Bars are the low carbon version of alloy 316 and it is protected from the grain boundary carbide precipitation formations. It is providing very good toughness even at the down to the cryogenic temperatures. These bars are also called as UNS S31603 bars that are finally used as the part of synthetic, oils and gas industries. Today our product is appreciated among the global market due to its ease of fabrication property and excellent corrosion resistant property. This Austenite structure is offering the top-notch harshness at the down to the cryogenic temperatures. We are providing this grade bars to our buyers at various specifications. It thus varies in standards, designations, surface finishes, and length.
|
Manufacturing Process |
Hot Rolled / Cold Rolled / Hot Forging / Rolling / Machining |
|
Dimension |
Outside Diameter in the range of 4mm |
|
Length |
2 meters to 7.5 meters ( 8 feet to 24 feet), or Custom Length as per Requirement |
|
Forms and Shape |
Round, Square, Hex (A/F), Rectangle, Billet, Ingot, HRAP, Bright, Shaft, Forging Etc. |
|
Finish |
Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
|
Standard |
ASTM A 484 / ISO h11 / ISO K12 Tolerances F8 / h8, h9, h10, h11, h12, k12, k13, A-484, EN-10060, DIN-1013 etc. |
|
Heat Treatment |
Condition A in which the bars are Annealed |
|
Surface Finish |
Belt Polished, up to Ra value = 0.2 um (12 RMS), and Grit Polished of up to 180 to 600 |
|
Value Added Services |
Rolling, Drill, Punch, CNC Machining, Sand Blasting, Shot Blasting, Heat Treatment, Anti-rust Paint, Polishing |
|
Packaging |
Loose / Wooden Pallet / Wooden Box / Plastic Cloth Wraps |
|
Grade |
C |
Mn |
Si |
P |
S |
Cr |
Mo |
Ni |
N |
|
SS 316 |
0.08 max |
2.0 max |
1.0 max |
0.045 max |
0.030 max |
16.00 - 18.00 |
2.00 - 3.00 |
11.00 - 14.00 |
67.845 min |
|
Density |
Melting Point |
Tensile Strength |
Yield Strength (0.2%Offset) |
Elongation |
|
8.0 g/cm3 |
1400 °C (2550 °F) |
Psi – 75000 , MPa – 515 |
Psi – 30000 , MPa – 205 |
35 % |
