ASTM 316 Stainless Steel Coil Overview

Type 316 is Like Type 304, which has exceptional fabrication and formability characteristics, is easy to clean and offers an excellent combination of high strength and light weight. Its defined as Austenitic chromium nickel stainless steel that also contains molybdenum and a higher nickel content than type 304 increase corrosion and oxidation resistance, reduce pitting particularly when exposed to various acids or other harsh environments and increase performance of the metal at elevated temperatures.

ASTM 316 Stainless Steel Coil Applications:

Food Industries

Chemical Industries

Electrical Industries

Gas Industries

Power Project

Storage and transportation

Stainless Steel Coil Specification

Product Name	Stainless Steel Coil
Material	200 series: 201, 202
	300 series: 304, 304L, 304H, 310S, 316, 316L, 317L, 321,310S,309S,2205,2507,2520
	400 series: 410, 410S,420, 430, 431, 440A,904L
Standard	AISI, ASTM, DIN, GB, JIS, SUS
Thickness	0.1-12mm or as your request
Width	1000, 1219, 1500, 1800, 2000mm or as your request
Treatment/Technique	Hot rolled, cold drawn
Surface	No.1, 2B, BA
Applications	Decorative /industrial/building material
Trade Terms	EXW, FOB, CFR, CIF
Delivery time	Shipped in 7-15 days after payment
Package	Standard sea-worthy package or as required
SEAWORTHY PACKING	20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high) about 24-26CBM
SEAWORTHY PACKING	40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high) about 54CBM 40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high) about 68CBM

Common number	ASTM	Mechinical Spefication
Common number	ASTM	Rm Mpa	Y.S.(Mpa)	A5
201	201	≥520	≥275	≥40
1Cr17Ni7		≥520	≥205	≥205
301	301	≥520	≥205	≥40
1Cr18Ni9		≥520	≥205	≥40
0Cr18Ni9		≥520	≥205	≥40
304	304	≥515	≥205	≥205
00Cr19Ni10		≥480	≥175	≥40
304L	304L	≥485	≥170	≥30
309S	309S	≥520	≥205	≥40
0Cr25Ni20		≥520	≥205	≥40
310S	310S	≥520	≥205	≥40
0Cr17Ni12Mo2		≥520	≥205	≥40
316	316	≥515	≥205	≥30
00Cr17Ni14Mo2		≥480	≥175	≥40
316L	316L	≥485	≥170	≥30
316Ti	316Ti	≥515	≥205	≥30
0Cr19Ni13Mo3		≥520	≥205	≥40
00Cr19Ni13Mo3		≥480	≥177	≥40
317L	317L	≥480	≥176	≥40
0Cr18Ni10Ti		≥520	≥205	≥40
321	321	≥515	≥205	≥30
409L		≥360	≥175	≥25
410	410	≥440	≥205	≥20
430	430	≥450	≥205	≥22
444	444	≥480	≥310	≥30
410S		≥420	≥290	≥33
2205/S31803/F51	2205	≥450	≥620	≥15
2507/S32750/F53	2507	≥550	≥800	≥25
630		≥520	≥785	≥18
904L/N08904		≥490	≥216	≥35
