U Type Steel Sheet Pile is most common sheet pile with obvious features such as: high intensity, water-proof property and so on. In bridge construction, u steel sheet pile has gradually played an important role and been popular with engineers. Steel sheet pile from our factory owns the high-class quality, forging by the advanced technology.
Product Name |
Cold Rolled U Type Steel Sheet Pile |
Brand |
liansen |
Technology |
Cold-rolled |
Standard |
ISO14001, ISO9001, CE, CE-EN1090, FPC, Cold-forming First Level |
Manufacturing Standard |
EN10249-1 / EN10249-2 |
Material |
Q235B, Q345B, S235, S240, SY295, S355, S430, S460, A690, ASTM A572 Grade 50, ASTM A572 Grade 60. All Chinese Standard, EN Standard, ASTM Standard and other standard material are available on request. |
Product catalog |
U Sheet Pile |
Used |
Products for building harbor, shipyard, port, bridge, cofferdam and so on. |
Width |
400mm-750mm |
Height |
150mm-630mm |
Thickness |
6mm-16mm |
Length |
No limited, as customer’s requirement |
Package: in 2ton -5tons bundles
shipping :in container or bulk
1. It combines great profile depth and has excellent statistic properties;
2. It is quite suitable for re-use due to the symmetrical form of the single element;
3. It is possible to assemble the piles into pairs in the factory, this way could improve the quality and performance of installation;
4. Good corrosion resistance performance.
Cold Rolled U Type Steel Sheet Pile is a kind of high efficient energy saving building materials.Widely used in embankment, a loading dock, dock, temporary Island, dyke, road,bridge, temporary pier revetment revetment, waterproof cofferdam, river, embankment reinforcement, retaining wall, retaining wall and the construction foundation pit bracing structure of foundation engineering.
