Wuxi liansen Metal Technology Co.,Ltd Stainless Steel exhaust tube Suppliers in India in sizes from 1/4 inch to 1/2 inch. and wall thickness from 0.035 to 0.049 in. Generally, these SS Coil Tubing is available in lengths up to 2300 feet, which is up to 30% long than traditional offerings. Stainless steel tube straighteners make stainless steel coiled tubing installation faster and easier. We offer a comprehensive range of SS exhaust tubes to our customers in various industry verticals. According to the different applications, the Stainless Steel Seamless exhaust tubes available in different sizes. Coil stainless steel tubing is widely used in the petrochemical, natural gas, oil and gas, and geothermal applications. We can customize the ideal Seamless Stainless Steel Tubing Coil for your unique application. Contact to liansen Metal for confirm availability and pricing.
Stainless Steel exhaust tube Outside Diameter |
1/16” through 3/4" |
Stainless Steel exhaust tube Thickness |
. 010" through .083” |
Stainless Steel exhaust tube Grades |
TP - 304,304L,316,316L,201 |
Stainless Steel Seamless Coil Tubing Specifications |
ASTM A213 (average wall) and ASTM A269 |
Stainless Steel Welded Coil Tubing Specifications |
ASTM A249 and ASTM A269 |
Outside Diameter (OD) |
Wall Thickness |
1/8” – 3/4” |
0.5mm – 4mm |
Outside Diameter (OD) |
Wall Thickness |
1/16” – 3/4” |
0.5mm – 4mm |
These stainless steel exhaust tube grades are sold to a wide range of industries/markets, due to their overall corrosion resistance and good machinability:
The below table shows the chemical composition of the used for Stainless Steel exhaust tubes:
STAINLESS STEEL exhaust tube GRADES |
UNS |
C |
Mn |
P |
S |
Si |
Cr |
Ni |
Mo |
Ti |
Nb |
N |
TP304 |
S30400 |
0.08 |
2 |
0.045 |
0.03 |
1 |
18.0-20.0 |
8.0-11.0 |
|
|
|
|
TP304L |
S30403 |
0.035 |
2 |
0.045 |
0.03 |
1 |
18.0-20.0 |
8.0-13.0 |
|
|
|
|
TP316 |
S3160 |
0.08 |
2 |
0.045 |
0.03 |
1 |
16.0-18.0 |
11.0-14.0 |
2.0-3.0 |
|
|
|
TP316L |
S31603 |
0.035 |
2 |
0.045 |
0.03 |
1 |
16.0-18.0 |
10.0-14.0 |
2.0-3.0 |
|
|
|
Material |
Heat |
Temperure |
Tensile Strength |
Yield Strength |
Elongation %, Min |
Treatment |
Min. |
Ksi (MPa), Min. |
Ksi (MPa), Min. |
||
|
º F(º C) |
|
|
||
TP304 |
Solution |
1900 (1040) |
75(515) |
30(205) |
35 |
TP304L |
Solution |
1900 (1040) |
70(485) |
25(170) |
35 |
TP316 |
Solution |
1900(1040) |
75(515) |
30(205) |
35 |
TP316L |
Solution |
1900(1040) |
70(485) |
25(170) |
35 |
