Our ASTM A554 TP316 tube has the capacity to withstand high temperature as well. Therefore the Alloy 316 tube is used in high temperature services as well. There are different specifications such as the ASTM A270 TP316 tube and different sizes ranging from ½ inches to 60 inches in different types. The UNS S31600 tubing produced by us is of high quality and standards. Please contact us for your SS 316 seamless tubing needs or welded 316 tubing needs. We are ready to provide.
Specifications |
ASME SA213 / ASTM A249 / ASTM A269 |
Dimensions |
ASME, ASTM, and API |
Size |
1/8″NB upto 30″NB |
Thickness |
0.35mm to 6.35mm OD in thickness ranging from 0.1mm to 1.2mm. |
Schedule |
Schedule 20, 30, 40, STD, 80, XS, 60, 80, 120, 140, 160, XXS |
Type |
ERW / Seamless / Fabricated / Welded / LSAW Tubes |
Form |
Square, Hydraulic, Round, Rectangular, Etc |
Length |
Double Random, Single Random, & Cut Length. |
End |
Beveled End, Plain End, Treaded |
RATES OF S.S. TUBES 316 PER MTR.
MM |
INCH |
SCH 5 |
SCH 10 |
SCH 40 |
15 |
1/2" |
226 |
295 |
352 |
20 |
3/4" |
289 |
371 |
453 |
25 |
1" |
359 |
579 |
684 |
32 |
1.1/4" |
450 |
744 |
882 |
40 |
1.1/2" |
517 |
859 |
1114 |
50 |
2" |
650 |
1084 |
1491 |
65 |
2.1/2" |
1007 |
1575 |
2550 |
80 |
3" |
1066 |
1933 |
3147 |
100 |
4" |
1378 |
2505 |
4489 |
125 |
5" |
2555 |
3330 |
6200 |
150 |
6" |
3053 |
3841 |
7305 |
200 |
8" |
4136 |
5661 |
11732 |
250 |
10" |
6594 |
7925 |
15672 |
300 |
12" |
8259 |
10076 |
20881 |
350 |
14" |
10550 |
12930 |
25200 |
Grade |
Density |
Electrical Resistivity (n.m) |
Mean Coefficient |
Modulus |
Thermal Conductivity |
Specific Heat from 0 to 1000C |
|||
0-3150C |
0-1000C |
0-5380C |
at 5000C |
at 1000C |
|||||
316 |
7750 |
720 |
16.2 |
15.9 |
17.0 |
200 |
18.7 |
14.2 |
500 |
STANDARD |
UNS |
BS |
GOST |
WERKSTOFF NR. |
JIS |
EN |
AFNOR |
SS 316 |
S31600 |
316S33 / 316S31 |
– |
1.4401 / 1.4436 |
SUS 316 |
X3CrNiMo17-13-3 / X5CrNiMo17-12-2 |
Z7CND17‐11‐02 |
Grade |
Mn |
C |
S |
Si |
Cr |
P |
Mo |
N |
Ni |
|
316 |
min. |
– |
|
– |
– |
16.0 |
– |
2.0-3.0 |
– |
10.0 |
max. |
2.0 |
0.035 |
0.030 |
0.75 |
18.0 |
0.045 |
|
– |
14.0 |
Grade |
Elongational |
Yield Properties |
Tensile Properties |
Hardness |
|
Brinell |
Rockwell B |
||||
316 |
40 |
205 |
515 |
217 |
95 |
