Prosaic Steel and Alloys is a well known worldwide Exporter of Stainless Steel 304 Pipes and Tubes, We are committed to provide each and every Customer with the Highest Standard of Customer service with Top Quality Standards. We deals in SS 304 Seamless Pipes in India & Overseas, offering a wide range of SS 304 Pipes and Tubes.
Specification |
ASTM A249, ASTM A269, ASTM A213, ASTM A312, ASTM A358, ASME SA249, ASME SA269, ASME SA213, ASME SA312, ASME SA358 EN 10216-5, EN 10217-7 |
Pipes Other Grades |
202, 304, 304L, 304H, 304LN, 309S, 310S, 316, 316L, 316H, 316Ti, 316LN, 317L, 321, 321H, 347, 347H, 904L, SMO 254, ALLOY 254, 6MO, 6MOLY, UNS S31254 ETC. |
Pipes Type |
Seamless / Welded / ERW / EFW / Cold Draw / Hot Finish / Cold Finish |
Pipes Form |
Round Pipes, Square Pipes, Rectangular Pipes |
Outer Diameter Size |
SEAMLESS - 1/2" NB TO 18" NB |
Wall Thickness |
SCH 20, 30, 80, 60, 120, 160, and 140, STD, XS, and XXS (3 mm to 100 mm Thickness) |
Length |
01 Meter to 12.5 Meters, Single Random Length, Double Random Length And Customize Size. |
Pipes Ends |
Plain Ends / Beveled Ends |
Delivery Conditions |
As Rolled, Formed, Stress Relieved, Annealed, Hardened, Tempered, Cold Draw |
Coating |
Electropolish, Mechanical Polish, Satin Finish, Passivated |
Other Testing |
Product Analysis, Transverse Tension Test, Flattening Test, Etching Test, Radiographic Examination, Stabilizing Heat Treatment, Intergranular Corrosion Test, Weld Decay Test, Magnetic Particle Detection, Grain Size Test, NACE 0175, Dual Grade, PWHT (POST WELD HEAT TREATMENT), Flare Test, Bend Test, Hardness Test, Tensile Test etc |
Dimension Tolerance |
All Pipes Is Manufactured and Inspected / Tested to the Relevant standards including ASTM and ASME |
Application |
Oil and Gas Industry, Power Plant, Chemical Industry, Refineries, Construction, Marine Application, Medical and Surgical Industry, Food Processing, Distilleries & Sugar Mills, Fats & Fertilizer, Cement, Paper, Pumps, Ship Builders etc. |
Value Added Services |
Draw / Expansion / Machining / Sand Blasting / Shot Blasting / Heat Treatment / Annealed / Bright Annealed / CNC Laser Cutting |
Packaging |
Loose / Bundle / Wooden Pallet / Wooden Box / Plastic Cloth Wraps / Plastic End Caps / Beveled Protector |
Shipment & Transportation |
By Road - Truck / Train, By Sea - Break-bulk Conventional Vessel / FCL (Full Container Load) / LCL (Less Container Load) / 20 Feet Container / 40 Feet Container / 45 Feet Container / High Cube Container / Open Top Container, By Air - Freighter Civil Passenger and Cargo Planes |
Material Test Certificate |
Manufacturer Test Certificate As Per EN10204 3.1, 3.2 / Laboratory Test Certificate From NABL Approved Lab. / Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS Etc. |
Grade |
C |
Ni |
Si |
N |
S |
Mn |
P |
Cr |
Mo |
|
SS 304 |
min. |
- |
8.0 |
- |
- |
- |
- |
- |
18.0 |
- |
max. |
0.08 |
10.5 |
0.75 |
0.10 |
0.030 |
2.0 |
0.045 |
20.0 |
|
Grade |
Tensile Strength (MPa) min |
Elongation (% in 50mm) min |
Yield Strength 0.2% Proof (MPa) min |
Hardness |
|
Rockwell B (HR B) max |
Brinell (HB) max |
||||
SS 304 |
515 |
40 |
205 |
92 |
201 |
STANDARD |
UNS |
WERKSTOFF NR. |
AFNOR |
EN |
JIS |
BS |
GOST |
SS 304 |
S30400 |
1.4301 |
Z7CN18‐09 |
X5CrNi18-10 |
SUS 304 |
304S31 |
08Х18Н10 |
